CPU

    Supports 6th Gen Intel® Core i3/i5/i7 processors, and Intel® Pentium® and Celeron® processors for Socket LGA1151

    Chipset

    Intel® H110 Chipset

    Main Memory

    2 x DDR4 memory slots, support up to 32GB

    - Supports DDR4 2133 MHz

    Dual channel memory architecture

    Supports Non-ECC, un-buffered memory

    Supports Intel® Extreme Memory Profile (XMP)

    * Please refer to Compatibility reports for more information of compatible memory.

    * DDR4 2133 MHz and higher memory modules will only run at maximum of DDR4 2133 MHz on XMP mode due to Intel® chipset limitation

    Slots

    1 x PCIe 3.0 x16 slot

    1 x PCIe 3.0 x1 slot

    1 x PCI slot

    Onboard Graphics

    1 x HDMI port, supports a maximum resolution of 4096x2160esam24Hz, 2560x1600esam60Hz

    - Support for HDMI 1.4 version.

    1 x VGA port, supports a maximum resolution of 1920x1200esam60Hz

    On-Board SATA

     Intel® H110 Chipset

    4 x SATA 6Gb/s ports

    USB

     Intel® H110 Chipset

    - 4 x USB 3.1 Gen1 (SuperSpeed USB) ports (2 ports on the back panel, 2 ports available through the internal USB connector)(optional)

    - 6 x USB 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB connectors)

    Audio

    Realtek® ALC887 Codec

    7.1-Channel High Definition Audio

    LAN

    1 x Realtek RTL8111H Gigabit LAN controller

    Back Panel I/O Ports

    - 1 x PS/2 keyboard port

    - 1 x PS/2 mouse port

    - 2 x USB 2.0 ports

    - 2 x USB 3.1 Gen1 ports

    - 1 x Serial port

    - 1 x Parallel port

    - 1 x VGA port

    - 1 x HDMI port

    - 1 x LAN (RJ45) port

    - 3 x audio jacks

    Internal I/O Connectors

    - 1 x 24-pin ATX main power connector

    - 1 x 4-pin ATX 12V power connector

    - 4 x SATA 6Gb/s connectors

    - 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)

    - 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports)

    - 1 x 4-pin CPU fan connector

    - 2 x 4-pin system fan connectors

    - 1 x Front panel audio connector

    - 2 x Front panel connectors

    - 1 x TPM module connector

    - 1 x Serial port connector

    - 1 x Chassis Intrusion connector

    - 1 x Clear CMOS jumper

    Dimension

    9.6 in. x 8.1 in. (24.3 cm x 20.5 cm) m-ATX Form Factor

    Mounting

    6 mounting holes
